Hobbywing Quicrun WP 880 Dual Motor Brushed ESC 30120301

Easy Operation
This ESC is specially designed for new beginners and intermediate modelers; it not only carries forward the outstanding quality of HOBBYWING  products but simplifies the operation.

Applicable to All Weather Conditions
The waterproof and dust-proof design allows the QUICRUN WP-860-Dual-Brushed to be used in all weather conditions without any issue of damage caused to the ESC from water or dust.

Built-in BEC
The built-in switch mode BEC with a maximum output of 6Amp and voltage of 5V make this ESC compatible with various servos.

High Reliability & Durability
Reliable hardware combined with advanced software technology allows the QUICRUN WP- 860-Dual-Brushed to not only provide high power output but also overload protection of the ESC circuit.

Multiple Running Modes
“Forward, Forward/Backward, Rock-crawler and boat” four running modes supported.

Easy to Use
This ESC features auto throttle calibration and parameter setting via jump caps is easy-to-use, especially applicable to new beginners.

Dual Output
This ESC can drive two brushed motors at the same time.
It’s cost-effective and applicable to low-speed crawlers and tanks which run two motors

Wide Application
This ESC is applicable to 1/10th, 1/8th scale touring cars, buggies, short-course trucks, monster trucks,
trucks as well as 1/10th, 1/8th scale rock crawlers, tanks and boats.

Specifications
Cont./Peak Current 80A/400A
Input 2-4S LiPo/6-12 Cells NiMH
BEC Output Switch Mode:6V/4A
Size 45.9×34.7×26.5mm
Weight 75g
Motors Brushed Motors
Vehicles 1/8th, 1/10th Touring Cars/Buggies/Trucks//Rock Crawlers
KV Rating/T Count
2S LiPo: T≥12T
3S LiPo: T≥18T
4S LiPo: T≥24T
(540/550/775 Size Motors)

Wires & Connectors
Input Wires Red-16AWG-150mm*2/Black-16AWG-150mm*1
Output Wires Blue-16AWG-100mm*2/Yellow-16AWG-100mm*2
Input Connectors No
Output Connectors 4.0 Bullet Connectors (Female)
(Note: All the wire length above is the original length not the length you see from the outside.)

ESC Programing via
SET Button on ESC Not Supported
LED Program Box Supported
LCD Program Box Not Supported
WiFi Module Not Supported
Program Port Dip Switch

Downloads
Download the manual here.
