Traxxas Servo digital high-torque 330 (blue) coreless metal gear ball bearing waterproof 2250

Traxxas Servo digital high-torque 330 (blue) coreless metal gear ball bearing waterproof 2250

High-Torque 330 Blue Servo
The Traxxas High-Torque 330 Blue servo combines maximum steering authority with a long list of high-performance features. The servo utilizes full metal gears, dual ball bearings, and an aluminum center section for added heat dissipation. A powerful coreless motor provides 330 ounce-inches of torque for the most demanding applications.* The High-Torque 330 servo is fully waterproof, not just “water resistant” and drops into most 1/10 Traxxas vehicles for that perfect factory fit.

The Power to Perform
With over 2.5 times more torque than the standard #2075 servo, the High-Torque 330 provides noticeably faster turning speed and works great with TSM^™ equipped vehicles. Traxxas High-Torque servos are the perfect upgrade for high-demand applications like Unlimited Desert Racer, Slash, Stampede, or almost any 1/10 Traxxas vehicle requiring extreme performance.

Replace the E-Revo’s dual servos with a single #2250 for lighter weight, more torque, and lightning-quick steering response. Elevate your steering performance to the next level with the High-Torque Blue 330 servo.

Waterproof Not “Water Resistant”
Traxxas knows the difference between “water resistant” and waterproof. Traxxas High-Torque servos are completely waterproof to give you the freedom to run when you want, where you want. Power through streams and bogs without fear while trucks with “water resistant” servos are stuck on the sidelines.

HIGH-TORQUE 330 BLUE FEATURES

• Factory fit for drop-in installation into Traxxas Models
• Fully waterproof, not “water resistant”
• Compatible with Traxxas Stability Management™ (TSM)
• 330 oz-in torque at 6.0V (23kg)
• 0.19 sec/60° at 6.0V
• Metal gears
• Dual ball bearings
• Coreless motor technology
• Aluminum center case

SPECIFICATIONS
Motor Type:         Coreless
Operating Voltage:         6.0 – 7.4V DC
Speed:         0.19 sec/60° at 6.0V
Torque:         330 oz-in at 6.0V
Weight:         64g
Gears:         Metal
Output Spline:         25T
Case:         Plastic top/bottom, anodized aluminum center
Controller:         Digital

APPLICATION GUIDE
Compatible with most Traxxas 1/10 scale electric models*
Compatible with TRX-4 models using High-Voltage BEC Kit #2262 and #8247X metal servo horn
Compatible with Traxxas nitro models using rechargeable 5-cell battery packs
Compatible with Maxx using adapter #7749 and servo arm from #5345R
Not recommended for X-Maxx
